https://www.brildor.com/en/corner-edge-rounder53507Corner and Straight Edge Rounder<p><a name="know-more"></a></p>
<h2>More information about the Corner and Straight Edge Rounder</h2>
<p> </p>
<p><strong>INDEX</strong></p>
<p>> <a href="#know-more1">Description</a></p>
<p>> <a href="#know-more2">Things to keep in mind</a></p>
<p>> <a href="#know-more3">What does the corner rounder include?</a></p>
<p>> <a href="#know-more4">Accessories</a></p>
<p>> <a href="#know-more5">User manual</a></p>
<p>> <a href="#know-more6">Measurements</a></p>
<p> </p>
<p><a name="know-more1"></a></p>
<p><strong>DESCRIPTION</strong></p>
<ul>
<li>Die cutter ideal for trimming the corners of business cards, photos, tags, brochures...</li>
<li>Blade with a <span class="azul-negrita">6 mm</span> radius of high hardness. Capable of cutting up to <span class="azul-negrita">10 mm</span> thickness of paper and up to <span class="azul-negrita">1.5 mm</span> of aluminium</li>
<li>Non-slip pads on the base to prevent slipping during use</li>
<li>Tool drawer with 2 compartments and waste drawer on the side</li>
<li>Alignment base with ruler markings and engraved blade types</li>
<li>Reusable cutting bases of<span class="azul-negrita"> Ø26 mm</span>. They can be used multiple times by rotating to a new side until completely worn out</li>
</ul>
<p> </p>
<p><a name="know-more2"></a></p>
<p><strong>THINGS TO KEEP IN MIND</strong></p>
<ul>
<li>Ensure the cutting base is in place before cutting</li>
<li>To use the corner rounder for the first time, lower the handle and remove the Allen key</li>
<li>Accessories are purchased separately</li>
</ul>
<p> </p>
<p><a name="know-more3"></a></p>
<p><strong>WHAT DOES THE CORNER ROUNDER INCLUDE?</strong></p>
<table>
<tbody>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>Alignment base</td>
</tr>
<tr>
<td><span class="azul-negrita">3</span></td>
<td>Cutting bases</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>L guide</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>Allen key with cylindrical end</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>R6 blade (radius <span class="azul-negrita">6 mm</span>)</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>Tool drawer</td>
</tr>
<tr>
<td><span class="azul-negrita">1</span></td>
<td>Waste drawer</td>
</tr>
<tr>
<td><span class="azul-negrita">1<br></span></td>
<td>User manual</td>
</tr>
</tbody>
</table>
<p> </p>
<p><a name="know-more4"></a></p>
<p><strong>ACCESSORIES</strong></p>
<p><strong>Cutting bases</strong></p>
<ul>
<li>Replacement cutting bases with a <span class="azul-negrita">25 mm</span> diameter. Easy to replace</li>
<li>Help absorb impact and pressure during cutting</li>
<li>Made of very resistant plastic</li>
<li>Each base can also be used multiple times</li>
</ul>
<p><strong>Blades</strong></p>
<ul>
<li>With different cutting angle types:
<ul>
<li><strong>R3.5</strong>: round cut with a radius of<span class="azul-negrita"> 3.5 mm </span>(<span class="azul-negrita">Ø7 mm</span>)</li>
<li><strong>R6</strong>: round cut with a radius of <span class="azul-negrita">6 mm </span>(<span class="azul-negrita">Ø12 mm</span>). Replacement blade for the one included with the corner rounder</li>
<li><strong>R10</strong>: round cut with a radius of <span class="azul-negrita">10 mm</span> (<span class="azul-negrita">Ø20 mm</span>)</li>
<li><strong>C15</strong>: straight cut of <span class="azul-negrita">20 mm</span>. Comes in a protective case<span class="azul-negrita"><br></span></li>
</ul>
</li>
<li>Easily interchangeable: unscrew, replace the blades, and screw back with the included Allen key</li>
</ul>
<p> </p>
<p><a name="know-more5"></a></p>
<p><strong>USER MANUAL</strong></p>
<p><a href="https://tinyurl.com/2cep3x72" target="_blank" rel="noopener">Corner and Straight Edge Rounder (.pdf - 0,38 MB)</a></p>
<p> </p>
<p><a name="know-more6"></a></p>
<p><strong>MEASUREMENTS</strong></p>
<p><strong>Machine</strong></p>
<table>
<tbody>
<tr>
<td><strong>Corner rounder (cm)<br></strong></td>
<td>
<p><span class="azul-negrita">14 x 27 x 14<br></span></p>
</td>
</tr>
<tr>
<td><strong>Blade (mm)<br></strong></td>
<td>
<p><span class="azul-negrita">67 x 19 x 18</span></p>
</td>
</tr>
<tr>
<td><strong>Alignment base (cm)<br></strong></td>
<td>
<p><span class="azul-negrita">11.2 x 11.2<br></span></p>
</td>
</tr>
<tr>
<td><strong>Cutting base (mm)</strong></td>
<td>
<p><span class="azul-negrita">Ø26 x 6.45</span></p>
</td>
</tr>
<tr>
<td><strong>Corner rounder weight (g)<br></strong></td>
<td>
<p><span class="azul-negrita">2204<br></span></p>
</td>
</tr>
</tbody>
</table>
<p><strong>Accessories</strong></p>
<table>
<tbody>
<tr>
<td>
<p><strong>Cutting base (mm)</strong></p>
</td>
<td><span class="azul-negrita">Ø25 x 6.15</span></td>
</tr>
<tr>
<td><strong>Blade (mm)</strong></td>
<td><span class="azul-negrita">67 x 19 x 18</span></td>
</tr>
</tbody>
</table>https://www.brildor.com/media/catalog/product/c/a/cantonera-easyedge-boquilla-corte-redondor6-d1_1.jpg139instock0139000https://www.brildor.com/media/catalog/product/c/a/cantonera-easyedge-boquilla-corte-redondor6-d1_1.jpg2474553506/Cutting Tools/Sign Making/Sign Making/Cutting Tools2025-02-03T10:11:29+0000
