Flame Retardant and Reflective Heat Transfer Film - Chemica Reflex 495
Reflective heat transfer vinyl with fireproof properties due to flame-retardant particles.
- Made of 200 µ grey PU
- Suitable for cotton, polyester, acrylic and cotton-polyester blended fabrics
- Sales units: 1 m and 10 m rolls, 50 cm wide
More information
Our availability is not enough?
Let us know how much you need
I WANT MORE
More information about the Flame Retardant and Reflective Heat Transfer Film - Chemica Reflex 495
INDEX
> Description
> Things to keep in mind
> Technical characteristics
> Transfer parameters
> Application instructions
> Washing recommendations
> Storage recommendations
> Weight
> Data sheet
DESCRIPTION
REFLEX 495 is a reflective PU (polyurethane) film for textile transfer onto garments requiring high visibility and safety.
- Its reflective particles activate in dark environments when the vinyl is exposed to a light source
- Complies with EN ISO 20471 for the manufacture of high visibility garments
- Certified under EN 15614, EN 14116, EN 11612 and EN 469 certifications which make it fireproof
- The 10-metre rolls have a Ø7.5 cm cardboard core
- The liner is a self-adhesive PET (polyester) film that acts as a carrier
- Made in France by Chemica
THINGS TO KEEP IN MIND
- Wait at least 24 hours before the first wash
TECHNICAL CHARACTERISTICS
| Vinyl |
Reflective polyurethane |
| Thickness (µ) |
200 |
| Support or liner |
PET film |
| Includes transporter |
Yes |
| Fabrics |
Polyester, cotton, acrylic and cotton-polyester blends |
| Cutting blade for vinyl cutter |
45º |
| Blockout(*) |
Yes |
| Discard |
Hot/Tibium |
(*) Prevents the colour of the textile from transferring to the vinyl during its application
TRANSFER PARAMETERS
- Knife blade: 45º
- Temperature: 160ºC
- Time:
- 3 seconds (first pressing)
- 15 seconds (second pressing)
- Pressure: 2.5 - 3.0 bar [medium pressure]
APPLICATION INSTRUCTIONS
- Cut your design in mirror image with a cutter plotter
- Weed out your excess vinyl
- Preheat the press to 160ºC
- Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
- Position the vinyl over the garment and cover with protective paper
- Press for 3 seconds, medium pressure
- Tibium peel the liner
- Press again for 15 seconds with the same parameters
WASHING RECOMMENDATIONS
| Washing |
Washing recommendation |
Dry cleaning |
Drying |
| Max. 40ºC |
Inside out |
Yes |
Yes |
STORAGE RECOMMENDATIONS
| Storage life |
Temperature |
Lightning |
Position |
| Up to 1 year |
Dry room (15-30ºC) |
Away from sunlight |
Vertical |
Weight
| Roll |
1 |
10 |
| Weight (kg) |
0.2 |
2 |
DATA SHEET
Data sheet Reflex 495 (.pdf - 0.34 MB)
More Information
| Ref. |
927618 |
https://www.brildor.com/en/flame-retardant-reflective-heat-transfer-vinyl
27618
Flame Retardant and Reflective Heat Transfer Film - Chemica Reflex 495
