Neon Heat Transfer Vinyl - Poli-Flex Turbo from Poli-Tape

More information about the Neon Heat Transfer Vinyl - Poli-Flex Turbo from Poli-Tape

INDEX

> Description

> Things to keep in mind

> Colour reference list

> Technical characteristics

> Transfer parameters for cotton and blends

> Transfer parameters for polyester

> Transfer parameters for nylon

> Application instructions for cotton and blends

> Application instructions for polyester

> Application instructions for nylon

> Wash resistance

> Weight

> Colour card

> Data sheet

> Safety data sheet

DESCRIPTION

POLI-FLEX TURBO is an ecologically proven cast PU (polyurethane) film with anti-sublimation or blockout properties for textile transfer.

• It can be applied at low temperature. This fact avoids the colour of the T-shirt to contaminate the colour of the vinyl
• Suitable for heat press and domestic iron
• The liner is a self-adhesive PET (polyester) film that acts as a carrier
• The 25-metre rolls have a Ø7.5 cm cardboard core
• The raw materials are ecologically inert, do not contain PVC, plasticizers or heavy metals and are certified in accordance with Oeko-Tex Standard 100 Class I
• Made in Germany by Poli-Tape

THINGS TO KEEP IN MIND

• Can be cut with any current plotter We recommend using a standard 45º knife
• If you use a Silhouette cutting plotter, apply the following parameters: blade 3, speed 5, and pressure 10
• It is recommended to test on textiles with a water-repellent coating to check that the vinyl adheres to the fabric

COLOUR REFERENCE LIST

Find Pantone, HEX, RGB, CMYK and RAL equivalents:

Colour reference list Poli-Flex Turbo (pdf - 0.54 MB)

TECHNICAL CHARACTERISTICS

^(*) It can be over-coated with another layer of vinyl to create multi-coloured composite designs

^(**) Prevents the colour of the textile from transferring to the vinyl during its application

TRANSFER PARAMETERS FOR COTTON AND BLENDS

Heat press

This vinyl can be applied at different temperatures:

• Temperature - Time:
  • 130ºC-5 seconds

  • 150ºC-4 seconds
  • 160ºC-3 seconds
• Pressure: 2.5 - 3.0 bar [medium pressure]

Iron

• Temperature: 350ºC
• Time: 5-10 seconds

TRANSFER PARAMETERS FOR POLYESTER

Heat press

• Temperature: 350ºC
• Pressure: 2.5 - 3.0 bar [medium pressure]
• Time: 5 seconds

Iron

• Temperature: 350ºC
• Time: 5 seconds

TRANSFER PARAMETERS FOR NYLON

Heat press

• Temperature: 150ºC
• Pressure: 2,0 bar [low temperature]
• Time:
  • 5 seconds (pre-pressed)
  • 5 seconds (heat transfer)
  • 10 seconds (heat bonding)

Iron

• Temperature: 350ºC
• Time:
  • 5 seconds (pre-pressed)
  • 5- 5 seconds (heat transfer)
  • 10 seconds (heat bonding)

APPLICATION INSTRUCTIONS FOR COTTON AND BLENDS

Suitable for application on cotton, cotton/polyester blends and polyester/acrylic.

Heat press

• Cut your design in mirror image with a cutter plotter
• Weed out your excess vinyl
• Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
• Position the vinyl on the garment
• Press at 130ºC (5 seconds), 150ºC (4 seconds) or 160ºC (3 seconds) with medium pressure, depending on the temperature that best suits the fabric
• Warm peel the liner

Iron

• Cut your design in mirror image with a cutter plotter
• Weed out your excess vinyl
• Pre-iron the garment for 5 seconds to remove wrinkles and moisture from the fabric
• Position the vinyl on the garment
• Iron at 130ºC for 5-10 seconds. The pressure must be exerted evenly over the entire vinyl
• Warm peel the liner

APPLICATION INSTRUCTIONS FOR POLYESTER

Heat press

• Cut your design in mirror image with a cutting plotter
• Weed out your excess vinyl
• Preheat the press to 130ºC
• Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
• Position the vinyl on the garment
• Press for 5 seconds, medium pressure
• Warm peel the liner

Iron

• Cut your design in mirror image with a cutting plotter
• Weed out your excess vinyl
• Pre-iron the garment for 5 seconds to remove wrinkles and moisture from the fabric
• Position the vinyl on the garment
• Iron at 130ºC for 5 seconds. The pressure must be exerted evenly over the entire vinyl

• Warm peel the liner
• Cover the vinyl with silicone paper and press for 10 seconds
• Remove the silicone-coated paper

APPLICATION INSTRUCTIONS FOR NYLON

Heat press

• Cut your design in mirror image with a cutter plotter
• Weed out your excess vinyl
• Preheat the press to 150ºC
• Place the garment on the press and pre-press for 5 seconds to remove wrinkles and moisture from the fabric
• Position the vinyl on the garment
• Press for 5 seconds, medium pressure
• Warm peel the liner
• Cover the vinyl with silicone paper and press for 10 seconds
• Remove the silicone-coated paper

Iron

• Cut your design in mirror image with a cutter plotter
• Weed out your excess vinyl
• Pre-iron the garment for 5 seconds to remove wrinkles and moisture from the fabric
• Position the vinyl on the garment
• Iron at 130ºC for 5-10 seconds. The pressure must be exerted evenly over the entire vinyl

• Warm peel the liner
• Cover the vinyl with silicone paper and press for 10 seconds
• Remove the silicone-coated paper

WASH RESISTANCE

• Washing resistance: 60ºC max
• Wash inside out
• Suitable for tumble dryer 100ºC
• You may use bleach and solvents

WEIGHTS

COLOUR CARD

Colour card Poli-Flex Turbo (pdf - 1,10 MB)

DATA SHEET

Data sheet Poli-Flex Turbo (.pdf - 0.36 kB)

SAFETY DATA SHEET

When used under normal conditions, this product does not generate or release any dangerous substances or hazardous chemicals. This is a non-hazardous product in accordance with the current GefStoffV and EU criteria. Therefore it is not necessary to prepare a Material Safety Data Sheet for this product. The Safety Data Sheet serves only to comply with the regulation to supply information in accordance with REACH Regulation (EC) No. 1907/2006 and is available on request. This is not a hazardous product with regards to transportation legislation; neither does it contain substances that are hazardous to water within the meaning of the federal water act. After use, dispose of the waste product in accordance with the local/national authorities.
