TURBO PRINT 4038 H2O is a printable thermo-adhesivePU (polyurethane) film for textile transfer on cotton, polyester, polyester-cotton, polyester-acrylic and nylon fabrics without water-repellent impregnation.
Printable on its matte side
The 10-metre roll has a Ø7.5 cm cardboard core
Oeko-Tex Standard 100 class I certifies that the raw materials used are environmentally friendly, free of PVC, solvents, plasticisers and heavy metals
Made in Germany by Poli-Tape
THINGS TO KEEP IN MIND
To transfer the design to the garment we recommend using the Poli-Tack 854 or Poli-Tack 870 transfer tape, available in Related Products
After printing, it should be left to dry. Transfer it to the garment once the ink is dry to the touch
TECHNICAL DETAILS
Vinyl
Water-based polyurethane opaque white
Thickness (μ)
90
Adhesive
Co-polyester hot melt
Carrier (μ)
Thermo-adhesive PET film 100
TRANSFER PARAMETERS
COTTON, POLYESTER, POLYESTER-COTTON AND POLYESTER-ACRYLIC
It can be applied at different temperatures:
Temperature - Time:
130ºC - 5 seconds
150ºC - 4 seconds
160ºC - 3 seconds
Pressure: 2.5 - 3.0 bar [medium pressure]
Pre-pressing of the garment: 4-5 seconds
NYLON
Temperature: 150ºC
Pressure: 2 - 0 bar [low pressure]
Press time: 5 seconds
Fixing time: 10 seconds
Pre-pressing of the garment: 150ºC, 4-5 seconds
APPLICATION INSTRUCTIONS
COTTON, POLYESTER, POLYESTER-COTTON AND POLYESTER-ACRYLIC
Print the design on the matte side in direct mode
Let the ink dry
Cut the vinyl with a cutting machine when the ink is dry to the touch
Weed out your excess vinyl
Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture
Position the vinyl on the garment
Press at 130ºC (5 seconds), 150ºC (4 seconds) or 160ºC (3 seconds) with medium pressure
Hot peel the liner
NYLON
Print the design on the matte side in direct mode
Let the ink dry
Cut the vinyl with a cutting machine when the ink is dry to the touch
Weed out your excess vinyl
Preheat the press to 150ºC
Place the garment on the press and pre-press for 5 seconds to remove wrinkles and moisture
Position the vinyl on the garment
Press for 4-5 seconds, low pressure
Hot peel the liner
Cover with protective paper and press at 150ºC for 10 seconds with low pressure
WASH RESISTANCE
Washing resistance: 60ºC max
Only colour or mild detergent
Wash inside out
Iron inside out
Suitable for tumble dryer (up to 100ºC)
WEIGHTS
Roll
1
10
Weight (kg)
0.126
1.675
DATA SHEET
We have adapted the formats to the needs of our customers, which may not match those listed in the following safety data sheet provided by the manufacturer.
When used under normal conditions, this product does not generate or release any dangerous substances or hazardous chemicals. This is a non-hazardous product in accordance with the current GefStoffV and EU criteria. Therefore it is not necessary to prepare a Material Safety Data Sheet for this product. The Safety Data Sheet serves only to comply with the regulation to supply information in accordance with REACH Regulation (EC) No. 1907/2006 and is available on request. This is not a hazardous product with regards to transportation legislation; neither does it contain substances that are hazardous to water within the meaning of the federal water act. After use, dispose of the waste product in accordance with the local/national authorities.
