Vinyl	Polyurethane
Thickness (µ)	135
Carrier or liner	PET film
Includes transporter	Yes
Fabrics	Outdoor and water-repellent
Blade for plotter cutting	45º
*Blockout^()**	Yes
Weeding	Cold

^(*) Prevents the fabric colour from transferring to the vinyl during application

TRANSFER PARAMETERS

Cutting blade: 45º
Temperature: 100 ºC
Time: 15 seconds
Pressure: 2.5 - 3.0 bar [medium pressure]

APPLICATION INSTRUCTIONS

Cut the design in mirror mode with a cutting plotter
Remove excess vinyl (weeding process)
Heat the press to 100 ºC
Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
Place the vinyl on the garment and protective paper over it
Press at medium pressure for 15 seconds
Remove the liner cold

WEIGHTS

Roll (m)	1	10
Weight (kg)	0.156	1.6

STORAGE RECOMMENDATIONS

Period	Temperature	Lighting	Position
Up to 1 year	Dry place (15-30 ºC)	Away from sunlight	Vertical

How to make metallic prints on t-shirts

The trendiest looks for this summer with textile vinyl

TECHNICAL SHEET

Sunmark Technical Sheet (.pdf - 0.437 MB)

Additional Information

More Information
Ref.	925315
