Heat Transfer Vinyl - Poli-Flex Nylon

Poli-Flex Nylon heat transfer vinyl from Poli-Tape suitable for elastic fabrics. Can be used on fabrics on which other films cannot be applied.

  • Made of polyurethane (PU) coated with a thermoplastic adhesive (Hot Melt) and 100 μ thickness
  • Suitable for nylon, lycra or water-repellent coated fabrics
  • Sale unit: 1 m, 5 m and 25 m rolls with a width of 50 cm

More information

Availability:
Shown on each product
Reward Points
Get free € to redeem on your next order by buying these products. Discover the Brildor Loyalty Program Get free € to redeem on your next order by buying these products. Discover the Brildor Loyalty Program



More information about Poli-Flex Nylon Heat Transfer Vinyl by Poli-Tape



INDEX

> Description

> Technical characteristics

> Transfer parameters

> Application instructions

> Washing resistance

> Weights

> Related posts

> Colour card

> Pantone colour equivalents

> Technical data sheet

> Safety data sheet





DESCRIPTION

POLI-FLEX NYLON is an eco-friendly PU (polyurethane) film for heat transfer on elastic and/or water-repellent fabrics, i.e., highly water-resistant.

  • Multi-layered with a special Hot Melt coating that melts and bonds to the fabric when heated. Once cooled, the vinyl regains its rigidity and adheres to the fabric
  • Does not crack when stretched
  • The carrier or liner is a self-adhesive PET (polyester) film that acts as a transport tape
  • 25-metre rolls have a cardboard core of Ø7.5 cm
  • The raw materials used are eco-friendly, PVC-free, free of plasticisers and heavy metals, and certified according to the ecological standard Oeko-Tex Standard 100 Category I
  • Manufactured in Germany by Poli-Tape





TECHNICAL CHARACTERISTICS

Vinyl Eco-friendly polyurethane
Thickness (µ) 100
Carrier or liner PET film
Includes transport tape Yes
Fabrics Nylon, lycra, and water-repellent fabrics
Blade for cutting machine 45º
Laser cutting Yes
Layerable(*) Yes
Weeding Warm

(*) Can be layered with another vinyl to create multi-colour designs





TRANSFER PARAMETERS

  • Cutting blade: 45º
  • Temperature: 150 ºC
  • Time:
    • 4 seconds (transfer)
    • 10 seconds (fixing)
  • Pressure: 2.0 bar [medium pressure]





APPLICATION INSTRUCTIONS

  • Cut the design in mirror image using a cutting machine
  • Remove the excess vinyl (weeding)
  • Preheat the press to 150 ºC
  • Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
  • Place the vinyl on the garment and cover it with protective paper
  • Press at medium pressure for 4 seconds
  • Remove the liner warm
  • Press again for 10 seconds with the same parameters to fix the vinyl





WASHING RESISTANCE

  • Washing resistance: max. 40 ºC
  • Wash the garment inside out.
  • Suitable for dry cleaning.
  • Detergents can be used.





WEIGHTS

Roll (m) 1 5 25
Weight (kg) 0.136 0.68 3.4





RELATED POSTS

Cutting vinyl: How to choose the right one for your garment

Printing T-shirts with vinyl: easier than ever!

The most fashionable looks for this summer with heat transfer vinyl





COLOUR CARD

Poli-Flex Nylon Colour Card (.pdf - 839 kB).





PANTONE COLOUR EQUIVALENTS

Pantone colour equivalents for Poli-Flex heat transfer vinyl (.pdf - 620 kB)





TECHNICAL DATA SHEET

Poli-Flex Nylon Technical Data Sheet (.pdf - 618 kB).





SAFETY DATA SHEET

Proper handling of this product will not result in the formation or release of hazardous components. This product is not classified as hazardous under the current GefStoffV legislation or the criteria of the European Union. Therefore, the preparation of a safety data sheet is not mandatory in this case. The safety data sheet is only provided to fulfil the information requirements under Regulation (EC) No. 1907/2006 (REACH) and can be sent upon request. This product is neither classified as hazardous under transport legislation nor composed of high-risk liquid substances, complying with household health regulations. The waste generated from the application and end-of-life cycle of the product must comply with the legal disposal standards of the relevant/national entities in charge.
