Retroreflective Heat Transfer Vinyl - Poli-Flex Reflex from Poli-Tape

Retroreflective heat transfer vinyl designed to give visibility to the work clothes of operators or workers who work in poorly lit areas.

  • Made up of metallised particles that reflect light
  • 3M and Turbo Silver Vinyl (4781 and 4783) comply with EN 20471 for high-visibility clothing
  • Sale units: 1 m, 5 m, 10 m and 25 m rolls, 50 cm wide

More information

Availability:
Shown on each product
Reward Points
Get free € to redeem on your next order by buying these products. Discover the Brildor Loyalty Program Get free € to redeem on your next order by buying these products. Discover the Brildor Loyalty Program

More information about the Poli-Flex Reflex heat transfer vinyl from Poli-Tape



INDEX

> Description

> Silver 3M (4781)

> Nylon (4882)

> Technical characteristics

> Transfer parameters

> Application instructions

> Nylon 4882 application instructions

> Wash resistance

> Weights

> Colour card

> Data sheets

> Safety data sheet





DESCRIPTION

POLI-FLEX REFLEX is a transfer film with retro-reflective properties to transfer onto textiles like cotton, polyester-cotton and polyester-acrylic without water-repellent coating, except Nylon vinyl which is suitable for nylon, lycra and water-repellent coated fabrics.

  • Its reflective particles activate in dark environments when the vinyl is exposed to a light source. They reflect in white, except for coloured vinyl
  • The Turbo Silver 4783 HTV can be applied on polyester garments at low temperature
  • Premium 4782 and Nylon 4882 conform to En 471, class 2, for photometric or minimum retro-reflective values
  • The liner is a self-adhesive PET (polyester) film that acts as a carrier sheet
  • The 25-metre rolls have a Ø7.5 cm cardboard core
  • The raw materials are ecologically inert, do not contain PVC, plasticizers or heavy metals and are certified in accordance with Oeko-Tex Standard 100 Class I
  • Made in Germany by Poli-Tape





SILVER 3M (4781)

  • Made of retro-reflective and fireproof 3M Scotchlite fabric
  • Excellent for converting workwear used in low-light environments into high-visibility and safety clothing





NYLON (4882)

  • Multi-layer. Hot melt coating causes the adhesive to melt and mould to the fabric. Once cold, the vinyl recovers its rigidity and bonds to the garment
  • Can cut patterns up to 3 mm





TECHNICAL CHARACTERISTICS

Code 4781 4782 4882 4783 4774 a 4780 -
4784 y 4785
HTV Silver 3M Premium Nylon Turbo Silver Colours
Material
vinyl
3M Scotchlite
Multilayer,
coating
Hot Melt
Film
retroreflective
Film
retroreflective
Film
retroreflective
Thickness (μ) 160 175 180 150 205
Support
or liner
PET film PET film PET film PET film PET film
Includes
carrier
Yes Yes Yes Yes Yes
Fabrics

Cotton,
blends
cotton-polyester
blends
y
polyester-acrylic

Cotton,
blends
cotton-polyester
blends
y
polyester-acrylic

Nylon,
lycra and
with
coating
water-repellent
Polyester,
cotton,
cotton-polyester
blends
y
polyester-acrylic
Cotton,
blends
cotton-polyester
blends
y
polyester-acrylic
TRANSFER PARAMETERS
Laser cutting Yes Yes Yes Yes Yes
Blade
for vinyl cutter
45º 45º 45º 45º 60º
Temperature (ºC) 160 160 150 130 (polyester)
160 (cotton)
145
Time (s) 15 15 4 (transfer)
10 (fixing)
5 8
Pressure (bar) 3,5
[medium pressure]
3,5
[medium pressure]
2 3
[medium pressure]
3
[medium pressure]
Discard Hot / Warm Hot / Warm Warm Hot / Warm Cold





APPLICATION INSTRUCTIONS FOR ALL VINYLS EXCEPT FOR NYLON 4882

Follow the steps using the transfer parameters indicated in the previous section.

  • Cut your design in mirror image with a cutter plotter
  • Weed out your excess vinyl
  • Heat the press to the temperature indicated for each type of vinyl
  • Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
  • Position the vinyl over the garment and cover it with protective paper
  • Press with the right pressure and temperature settings for each type of vinyl
  • Hot or cold peel the liner depending on the type of vinyl



APPLICATION INSTRUCTIONS NYLON 4882

  • Cut your design in mirror image with a cutter plotter
  • Weed out your excess vinyl
  • Preheat the press to 150ºC
  • Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
  • Position the vinyl over the garment and cover it with protective paper
  • Press for 4 seconds, medium pressure
  • Warm peel the liner
  • Press again for 10 seconds with the same parameters





WASH RESISTANCE

  • Washing resistance: 40°C max. (Nylon) or 60ºC (other vinyls)
  • Wash inside out
  • Tumble dryer safe (except Nylon)
  • 3M Silver and Nylon vinyls are resistant to washing with detergent
  • The Nylon HTV is suitable for dry cleaning





WEIGHTS

Roll 1 5 10
25
Weight (kg) 0.213 1.065 3
6.040





COLOUR CARD

Colour card for Poli- Flex and Reflex HTV (.pdf - 1.40 MB)





DATA SHEETS

Data sheet for Poli-Flex and Reflex SILVER 3M 4781 HTV (.pdf - 47 kB)

Data sheet for Poli-Flex and Reflex Premium 4782 HTV (.pdf - 35 kB)

Data sheet for Poli-Flex and Reflex Nylon 4882 HTV (.pdf - 35 kB)

Data sheet for Poli-Flex and Turbo Reflex Silver 4783 HTV (.pdf - 35 kB)

Data sheet for Poli-Flex Reflex Colours HTV (.pdf - 35 kB)





SAFETY DATA SHEET

When used under normal conditions, this product does not generate or release any dangerous substances or hazardous chemicals. This is a non-hazardous product in accordance with the current GefStoffV and EU criteria. Therefore it is not necessary to prepare a Material Safety Data Sheet for this product. The Safety Data Sheet serves only to comply with the regulation to supply information in accordance with REACH Regulation (EC) No. 1907/2006 and is available on request. This is not a hazardous product with regards to transportation legislation; neither does it contain substances that are hazardous to water within the meaning of the federal water act. After use, dispose of the waste product in accordance with the local/national authorities.
