The diazo bag for the 1 kg emulsion contains approximately 4 grams, and the one for the 5 kg emulsion contains 20 grams
The mixture is made in a 1:1 ratio, for example, if you use half of the emulsion, you should use half of the diazo bag
Photosensitive liquid that reacts to light, so it should be applied in a dark and enclosed place
It is not recommended to expose this emulsion with LED lamps
It is advisable to clean the screen before applying the emulsion to ensure a thin and uniform layer. Any dust particles could leave pores in the design
Store in a place with a temperature between 5 °C and 30 °C
TECHNICAL DATA
Reference
048781
048780
Format (kg)
Jar of 1
Jar of 5
Appearance
Viscous blue liquid
Viscous blue liquid
Container (g)
Ø11.2 x 14.5
Ø23.4 x 17.5
Weight (kg)
1.077
5.341
INSTRUCTIONS FOR USE
Prepare the amount of diazo and emulsion to be used in a 1:1 ratio
Wash and remove grease or any contaminants from the screen using a degreaser
Gradually add the diazo sensitizer to the emulsion and mix them using a spatula until fully integrated
Let the mixture sit until the bubbles are gone (estimated time 20 min)
Slowly coat both sides of the screen mesh using a squeegee. Remember to apply it in a dark and enclosed place
https://www.brildor.com/en/screen-printing-emulsion-brildor48842Screen Printing Emulsion - Brildor<p><a name="know-more"></a></p>
<h2>More information about Screen Printing Emulsion Brildor</h2>
<p> </p>
<p><strong>INDEX</strong></p>
<p>> <a href="#know-more1">Things to keep in mind</a></p>
<p>> <a href="#know-more2">Technical data</a></p>
<p>> <a href="#know-more3">Instructions for use</a></p>
<p>> <a href="#know-more4">Technical sheet</a></p>
<p>> <a href="#know-more5">Safety sheet</a></p>
<p> </p>
<p><a name="know-more1"></a></p>
<p><strong>THINGS TO KEEP IN MIND</strong></p>
<ul>
<li>The diazo bag for the <span class="azul-negrita">1 kg</span> emulsion contains approximately <span class="azul-negrita">4 grams</span>, and the one for the <span class="azul-negrita">5 kg</span> emulsion contains <span class="azul-negrita">20 grams</span></li>
<li>The mixture is made in a 1:1 ratio, for example, if you use half of the emulsion, you should use half of the diazo bag</li>
<li>Photosensitive liquid that reacts to light, so it should be applied in a dark and enclosed place</li>
<li>It is not recommended to expose this emulsion with LED lamps</li>
<li>It is advisable to clean the screen before applying the emulsion to ensure a thin and uniform layer. Any dust particles could leave pores in the design</li>
<li>Store in a place with a temperature between <span class="azul-negrita">5 °C</span> and <span class="azul-negrita">30 °C</span></li>
</ul>
<p> </p>
<p><a name="know-more2"></a></p>
<p><strong>TECHNICAL DATA</strong></p>
<table>
<tbody>
<tr>
<td><strong>Reference</strong></td>
<td style="text-align: center; vertical-align: middle;"><strong>048781</strong></td>
<td style="text-align: center; vertical-align: middle;"><strong>048780</strong></td>
</tr>
<tr>
<td>Format (kg)</td>
<td style="text-align: center; vertical-align: middle;">Jar of <span class="azul-negrita">1</span></td>
<td style="text-align: center; vertical-align: middle;">Jar of <span class="azul-negrita">5</span></td>
</tr>
<tr>
<td>Appearance</td>
<td style="text-align: center; vertical-align: middle;">Viscous blue liquid</td>
<td style="text-align: center; vertical-align: middle;">Viscous blue liquid</td>
</tr>
<tr>
<td>Container (g)</td>
<td style="text-align: center; vertical-align: middle;"><span class="azul-negrita">Ø11.2 x 14.5</span></td>
<td style="text-align: center; vertical-align: middle;"><span class="azul-negrita">Ø23.4 x 17.5</span></td>
</tr>
<tr>
<td>Weight (kg)</td>
<td style="text-align: center; vertical-align: middle;"><span class="azul-negrita">1.077</span></td>
<td style="text-align: center; vertical-align: middle;"><span class="azul-negrita">5.341</span></td>
</tr>
</tbody>
</table>
<p> </p>
<p><a name="know-more3"></a></p>
<p><strong>INSTRUCTIONS FOR USE</strong></p>
<ul>
<li>Prepare the amount of diazo and emulsion to be used in a 1:1 ratio</li>
<li>Wash and remove grease or any contaminants from the screen using a degreaser</li>
<li>Gradually add the diazo sensitizer to the emulsion and mix them using a spatula until fully integrated</li>
<li>Let the mixture sit until the bubbles are gone (estimated time <span class="azul-negrita">20 min</span>)</li>
<li>Slowly coat both sides of the screen mesh using a squeegee. Remember to apply it in a dark and enclosed place</li>
<li>Dry the screen</li>
</ul>
<p> </p>
<p><a name="know-more4"></a></p>
<p><strong>TECHNICAL SHEET<br></strong></p>
<p><a title="Technical sheet screen printing emulsion" href="https://www.brildor.com/media/upload/descargas/Ficha_Tecnica_Emulsion_Diazo_Serigrafia_Inknovators.pdf" target="_blank" rel="nofollow noopener">Technical sheet screen printing emulsion (.pdf - 0.22 MB)</a></p>
<p> </p>
<p><a name="know-more5"></a></p>
<p><strong>SAFETY SHEET<br></strong></p>
<p><a title="Safety sheet screen printing emulsion" href="https://www.brildor.com/media/upload/descargas/Ficha_Seguridad_Emulsion_Diazo_Serigrafia_Inknovators.pdf" target="_blank" rel="nofollow noopener">Safety sheet screen printing emulsion (.pdf - 0.35 MB)</a></p>https://www.brildor.com/media/catalog/product/e/m/emulsion-diazo-dual-serigrafia-brildor-d3.jpg19.99outofstock019.99000https://www.brildor.com/media/catalog/product/e/m/emulsion-diazo-dual-serigrafia-brildor-d3.jpg1577615778260414312849605/Screen Printing/Screen Printing/Screen Preparation2022-10-19T07:11:18+0000
