With a flat platform that makes it capable of working with materials up to 2 cm thick. Unlike those cutting machines using rollers, Curio 2 is able to engrave on hard surfaces such as wood, acrylic and metals using the tool from engraving.
Flat platform: keeps the material static while the head moves in all 3 axes, allowing you to work with rigid and thick materials
Electrostatic bed: holds the materials in place and aligns them without the need for rollers or cutting mats. Includes a sheet that allows you to secure the material and protect the electrostatic bed from cuts. Replacements available in Related Products
Dual-head carriage: allows you to work with 2 tools simultaneously
Versatile: use the cutting plotter as an engraver, puncher, and even apply foil with the additional Power Tools
Complete: includes the Auto Blade self-adjusting blade that cuts materials up to 1 mm thick. You can separately purchase the Kraft Blade, which allows you to cut 3 mm materials (see Related Products)
Intelligent Path technology: facilitates precise cutting of ultra-thin paper and multi-layer cuts
Automatic detection sensors: for tools and material thickness measurement
Compatible materials: you can place materials up to 20 mm thick (notebooks, wood panels, acrylics, etc.) on the cutting plotter
Compatible with a variety of Silhouette tools: which you can purchase in Related Products
Connectivity: via USB 2.0 or Bluetooth®
Silhouette Studio® software: Compatible with Windows and Mac OS. Advanced versions such as Studio Designer or Studio Business are also available (see Related Products)
Warranty: 3 years against manufacturing defects
ENGRAVING TOOL (REF. 053571)
Electrically connected engraver to the plotter, uses metal contacts and pins that attach to the carriage to rotate the tip
High-speed milling cutter for grinding and engraving hard surfaces
Automatic detection of the Power Engraver tool, once inserted into the carriage 2, the Silhouette Studio® software recognizes it without the need to select it
Allows you to adjust pressure, speed, depth, and other parameters from the software
It is recommended to use the waste tray during engraving to protect the plotter from debris
WASTE TRAY (REF. 053580)
The Debris Tray protects the machine from engraving debris and prevents possible damage when using other electric tools
Easy installation. Remove the electrostatic bed and replace it with the waste tray
Working area of 35 x 35 cm
THINGS TO KEEP IN MIND
We will not accept the return of this machine if the serial number has been registered or the software has been downloaded from the manufacturer's website, as once this is done, the machine is permanently and irreversibly linked to the customer
To check the proper functioning of the plotter, it is not necessary to register the serial number on the manufacturer's website. It is recommended to perform tests before registering
The warranty does not cover: consumables, moving parts, or anything that is subject to wear and tear from use. Nor does it cover breakages resulting from impacts, accidents, misuse, or abuse
https://www.brildor.com/en/silhouette-curio-2-vinyl-cutter51074Silhouette Curio 2 - Cutting & Engraving Machine<p><a name="know-more"></a></p>
<h2>More information about the Silhouette Curio 2 Cutting and Engraving Plotter</h2>
<p> </p>
<p><strong>INDEX</strong></p>
<p>> <a href="#know-more1">Features</a></p>
<p>> <a href="#know-more7">Engraving Tool (Ref. 053571)</a></p>
<p>> <a href="#know-more10">Protective Sheet (Ref. 053579)</a></p>
<p>> <a href="#know-more8">Waste Tray (Ref. 053580)</a></p>
<p>> <a href="#know-more0">Things to keep in mind</a></p>
<p>> <a href="#know-more4">User Manual</a></p>
<p>> <a href="#know-more2">What's included with the Silhouette Curio 2 cutting plotter?</a></p>
<p>> <a href="#know-more9">Instructions for using the engraving tool</a></p>
<p>> <a href="#know-more5">Tools compatible with Curio 2</a></p>
<p>> <a href="#know-more3">Technical data</a></p>
<p>> <a href="#know-more6">Related posts</a></p>
<p> </p>
<p><a name="know-more1"></a></p>
<p><strong>FEATURES</strong></p>
<ul>
<li><strong>Flat platform:</strong> keeps the material static while the head moves in all 3 axes, allowing you to work with rigid and thick materials</li>
<li><strong>Electrostatic bed:</strong> holds the materials in place and aligns them without the need for rollers or cutting mats. Includes a sheet that allows you to secure the material and protect the electrostatic bed from cuts. Replacements available in <strong>Related Products</strong></li>
<li><strong>Dual-head carriage:</strong> allows you to work with 2 tools simultaneously</li>
<li><strong>Versatile:</strong> use the cutting plotter as an engraver, puncher, and even apply foil with the additional <em>Power Tools</em></li>
<li><strong>Complete:</strong> includes the Auto Blade self-adjusting blade that cuts materials up to <span class="azul-negrita">1 mm</span> thick. You can separately purchase the Kraft Blade, which allows you to cut <span class="azul-negrita">3 mm</span> materials (see <strong>Related Products</strong>)</li>
<li><strong>Intelligent Path technology:</strong> facilitates precise cutting of ultra-thin paper and multi-layer cuts</li>
<li><strong>Automatic detection sensors:</strong> for tools and material thickness measurement</li>
<li><strong>Compatible materials:</strong> you can place materials up to <span class="azul-negrita">20 mm</span> thick (notebooks, wood panels, acrylics, etc.) on the cutting plotter</li>
<li><strong>Compatible with a variety of Silhouette tools:</strong> which you can purchase in <strong>Related Products</strong></li>
<li><strong>Connectivity:</strong> via USB 2.0 or Bluetooth<sup>®</sup></li>
<li><strong><a class="azul-claro-brildor" href="https://www.silhouetteamerica.com/setup/es" target="_blank" rel="noopener">Silhouette Studio<sup>®</sup> software:</a></strong> Compatible with Windows and Mac OS. Advanced versions such as Studio Designer or Studio Business are also available (see <strong>Related Products</strong>)</li>
<li><strong>Warranty:</strong> 3 years against manufacturing defects</li>
</ul>
<p> </p>
<p><a name="know-more7"></a></p>
<p><strong>ENGRAVING TOOL (REF. 053571)</strong></p>
<ul>
<li>Electrically connected engraver to the plotter, uses metal contacts and pins that attach to the carriage to rotate the tip</li>
<li>High-speed milling cutter for grinding and engraving hard surfaces</li>
<li>Automatic detection of the Power Engraver tool, once inserted into the <strong>carriage 2</strong>, the Silhouette Studio® software recognizes it without the need to select it</li>
<li>Allows you to adjust pressure, speed, depth, and other parameters from the software</li>
<li>It is recommended to use the waste tray during engraving to protect the plotter from debris</li>
</ul>
<p> </p>
<p><a name="know-more8"></a></p>
<p><strong>WASTE TRAY (REF. 053580)</strong></p>
<ul>
<li>The Debris Tray protects the machine from engraving debris and prevents possible damage when using other electric tools</li>
<li>Easy installation. Remove the electrostatic bed and replace it with the waste tray</li>
<li>Working area of <span class="azul-negrita">35 x 35 cm</span></li>
</ul>
<p> </p>
<p><a name="know-more0"></a></p>
<p><strong>THINGS TO KEEP IN MIND</strong></p>
<ul>
<li>We will not accept the return of this machine if the serial number has been registered or the software has been downloaded from the manufacturer's website, as once this is done, the machine is permanently and irreversibly linked to the customer</li>
<li>To <strong>check the proper functioning of the plotter, it is not necessary to register</strong> the serial number on the manufacturer's website. It is recommended to perform tests before registering</li>
<li>The warranty <strong>does not cover</strong>: consumables, moving parts, or anything that is subject to wear and tear from use. Nor does it cover breakages resulting from impacts, accidents, misuse, or abuse</li>
</ul>
<p> </p>
<p><a name="know-more4"></a></p>
<p><strong>USER MANUAL</strong></p>
<p><a title="Silhouette Curio 2 Cutting Plotter User Manual (.pdf - 5.65 MB)" href="https://tinyurl.com/ym2ebl5g" target="_blank" rel="nofollow noopener">Silhouette Curio 2 Cutting Plotter User Manual (.pdf - 5.65 MB)</a></p>
<p> </p>
<p><a name="know-more2"></a></p>
<p><strong>WHAT'S INCLUDED WITH THE SILHOUETTE CURIO 2 CUTTING PLOTTER?</strong></p>
<table>
<tbody>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>Auto Blade self-adjusting blade (tool holder 1)</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>Blade adjustment tool</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>Electrostatic bed</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>Protective sheet for electrostatic bed</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>Adhesive tape</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>Safety manual</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>Silhouette Studio® software (downloadable) for Windows and Mac OS</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">1</span></td>
<td>One-month subscription to the Silhouette Design Store</td>
</tr>
<tr>
<td style="text-align: right;"><span class="azul-negrita">100</span></td>
<td>Exclusive designs available with registration</td>
</tr>
</tbody>
</table>
<p> </p>
<p><a name="know-more9"></a></p>
<p><strong>INSTRUCTIONS FOR USING THE ENGRAVING TOOL</strong></p>
<ul>
<li>Place the waste tray</li>
<li>Put the material on the tray and secure it with tape</li>
<li>Place the engraving tool in the right tool holder of the carriage, marked with number 2</li>
<li>The plotter will automatically detect it</li>
<li>Position the carriage over the material, place a sheet of paper on top, and press the height detection button</li>
<li>Load the design to be engraved in the Silhouette Studio® software</li>
<li>Go to the special tools panel and select the engraving tool</li>
<li>Choose the type of fill you prefer</li>
<li>Go to the send panel and create a new material type</li>
<li>Select the Curio 2 icon</li>
<li>Click on the carriage 2 tab and choose Others from the dropdown on the right</li>
<li>Add the drilling action from the (+) icon</li>
<li>Modify the parameters as desired and save</li>
<li>The plotter is ready to start engraving</li>
</ul>
<p> </p>
<p><a name="know-more5"></a></p>
<p><strong>TOOLS COMPATIBLE WITH CURIO 2</strong></p>
<table>
<tbody>
<tr>
<td style="text-align: center;"><strong>REF.</strong></td>
<td style="text-align: center;"><strong>TYPE</strong></td>
<td style="text-align: center;"><strong>MODELS <br></strong></td>
</tr>
<tr>
<td style="text-align: center;"><a href="https://www.brildor.com/es/cuchilla-de-corte-autoajustable-para-silhouette-cameo-4" target="_blank" rel="noopener">038590</a></td>
<td style="text-align: center;">Auto Blade</td>
<td style="text-align: left;">Portrait 3, 4; Curio 2; Cameo 4, Plus and Pro; Cameo 5, Plus</td>
</tr>
<tr>
<td style="text-align: center;"><a href="https://www.brildor.com/es/cuchillas-autodetectables-silhouette" target="_blank" rel="noopener">049839</a></td>
<td style="text-align: center;">Premium</td>
<td style="text-align: left;">Portrait 3, 4; Curio 2; Cameo 4, Plus and Pro; Cameo 5, Plus</td>
</tr>
<tr>
<td style="text-align: center;"><a href="https://www.brildor.com/es/cuchillas-autodetectables-silhouette" target="_blank" rel="noopener">049838</a></td>
<td style="text-align: center;">Deep Cut</td>
<td style="text-align: left;">Portrait 3, 4; Curio 2; Cameo 4, Plus and Pro; Cameo 5, Plus</td>
</tr>
<tr>
<td style="text-align: center;"><a href="https://www.brildor.com/es/cuchillas-autodetectables-silhouette" target="_blank" rel="noopener">049840</a></td>
<td style="text-align: center;">Kraft Blade 2 mm</td>
<td style="text-align: left;">Portrait 3, 4; Curio 2; Cameo 4, Plus and Pro; Cameo 5, Plus</td>
</tr>
<tr>
<td style="text-align: center;"><a href="https://www.brildor.com/es/cuchilla-de-corte-kraft-blade-para-plotter-silhouette-cameo-4" target="_blank" rel="noopener">038688</a></td>
<td style="text-align: center;">Kraft Blade 3 mm</td>
<td style="text-align: left;">Curio 2; Cameo 4, Plus and Pro; Cameo 5, Plus</td>
</tr>
<tr>
<td style="text-align: center;"><a href="https://www.brildor.com/es/portacuchillas-cuchillas-compatibles-plotters-corte-silhouette" target="_blank" rel="noopener">053413</a></td>
<td style="text-align: center;">30º Blade</td>
<td style="text-align: left;">Portrait 3, 4; Curio 2; Cameo 4, Plus and Pro; Cameo 5, Plus</td>
</tr>
<tr>
<td style="text-align: center;"><a href="https://www.brildor.com/es/portacuchillas-cuchillas-compatibles-plotters-corte-silhouette" target="_blank" rel="noopener">053413</a></td>
<td style="text-align: center;">45º Blade</td>
<td style="text-align: left;">Portrait 3, 4; Curio 2; Cameo 4, Plus and Pro; Cameo 5, Plus</td>
</tr>
<tr>
<td style="text-align: center;"><a href="https://www.brildor.com/es/portacuchillas-cuchillas-compatibles-plotters-corte-silhouette" target="_blank" rel="noopener">053413</a></td>
<td style="text-align: center;">60º Blade</td>
<td style="text-align: left;">Portrait 3, 4; Curio 2; Cameo 4, Plus and Pro; Cameo 5, Plus</td>
</tr>
<tr>
<td style="text-align: center;"><a href="https://www.brildor.com/es/cuchilla-punching-para-silhouette-cameo-4" target="_blank" rel="noopener">038670</a></td>
<td style="text-align: center;">Punching</td>
<td style="text-align: left;">Curio 2; Cameo 4, Plus and Pro; Cameo 5, Plus</td>
</tr>
<tr>
<td style="text-align: center;"><a href="https://www.brildor.com/es/cuchilla-rotatoria-para-textil-para-silhouette-cameo-4" target="_blank" rel="noopener">038669</a></td>
<td style="text-align: center;">Textile Rotary</td>
<td style="text-align: left;">Curio 2; Cameo 4, Plus and Pro; Cameo 5, Plus</td>
</tr>
</tbody>
</table>
<p> </p>
<p><a name="know-more3"></a></p>
<p><strong>TECHNICAL DATA</strong></p>
<table>
<tbody>
<tr>
<td><strong>Model</strong></td>
<td>SILH-CURIO-2-4T</td>
</tr>
<tr>
<td><strong>Cutting area (cm | inches)</strong></td>
<td><span class="azul-negrita">30.48 x 30.48 | 12 x 12</span></td>
</tr>
<tr>
<td><strong>Maximum cutting thickness (mm)</strong></td>
<td><span class="azul-negrita">3</span></td>
</tr>
<tr>
<td><strong>Maximum cutting force tool holder 1 (kg)</strong></td>
<td><span class="azul-negrita">0.3</span></td>
</tr>
<tr>
<td><strong>Maximum cutting force tool holder 2 (kg)</strong></td>
<td><span class="azul-negrita">5</span></td>
</tr>
<tr>
<td><strong>Maximum material thickness (mm)</strong></td>
<td><span class="azul-negrita">20</span></td>
</tr>
<tr>
<td><strong>Interface</strong></td>
<td>USB 2.0 (full speed) | Bluetooth<sup>®</sup> </td>
</tr>
<tr>
<td><strong>Silhouette Studio® software version requirements</strong></td>
<td>4.5.700 or higher</td>
</tr>
<tr>
<td><strong>System requirements</strong></td>
<td>
<p><span style="font-weight: 400;">Windows 10, MacOS X 10.14 (64-bit) or later</span></p>
</td>
</tr>
<tr>
<td><strong>Dimensions (cm)</strong></td>
<td><span class="azul-negrita">61.1 x 50.5 x 23.9</span></td>
</tr>
<tr>
<td><strong>Packaging (cm)</strong></td>
<td><span class="azul-negrita">66.8 x 57.4 x 31.2</span></td>
</tr>
<tr>
<td><strong>Net weight (kg)</strong></td>
<td><span class="azul-negrita">10.8</span></td>
</tr>
<tr>
<td><strong>Gross weight (kg)</strong></td>
<td><span class="azul-negrita">13.1</span></td>
</tr>
</tbody>
</table>
<p> </p>
<p><a name="know-more6"></a></p>
<p><strong>RELATED POSTS</strong></p>
