Sublimable Silver Glossy Aluminium Panels Chromaluxe
Large format photographic panels customisable dye sublimation printing . Ideal for studios and photo labs.
Chromaluxe quality metallised aluminium with glossy finish
Thickness: 1,14 mm
The panel Ref. 027563 is sold with a minimum of 6 units
More information
Our availability is not enough?
Let us know how much you need
I WANT MORE
Demonstration video of the panels Chromaluxe
More information about Sublimable Silver Glossy Aluminium Panels Chromaluxe
INDEX
> Description
> Things to keep in mind
> Dimensions
> Recommended instructions and parameters for sublimation printing
DESCRIPTION
Rounded corners, except panels Ref. 039600 and Ref. 027563 which have straight corners
Resistant to scratches, abrasions and UV (ultraviolet) rays
Silk-screen effect that allows dry erase with special markers for this type of blackboard
Thin and light
THINGS TO KEEP IN MIND
The backing is purchased separately, you will find it in Related Products . Adheres to the back of the board using the included double-sided adhesive
The printable side of the board is supplied covered with protective plastic film
DIMENSIONS
Article number Name Dimensions (cm) Thickness (mm) Corners
027145 15 x 20 cm (4:3)
20 x 15 1,14 Rounded
012416 20 x 25 cm (5:4)
25,4 x 20,3 1,14 Rounded
027161 20 x 30 cm (3:2)
30 x 20 1,14 Rounded
027162 30 x 30 cm (1:1)
30 x 30 1,14 Rounded
027163 30 x 40 cm (4:3)
40 x 30 1,14 Rounded
039600 30 x 61 cm
61 x 30,5 1,14 Straight
009060 40 x 50 cm (5:4)
50,8 x 40,6 1,14 Rounded
027164 40 x 61 cm (3:2)
61 x 40,6 1,14 Rounded
027563 60 x 120 cm
120 x 60 1,14 Straight
RECOMMENDED INSTRUCTIONS AND PARAMETERS FOR SUBLIMATION PRINTING
Parameters are given as a guide only. It is recommended to carry out preliminary tests in order to make the necessary adjustments before starting production.
Print the design in mode mirror
Preheat the press to 200 ºC
Place the panel on the plate and the printed design on the panel. Secure with heat adhesive tape
Close the press at medium pressure for 90 seconds
With the help of a protective glove, remove the freshly sublimated panel
Carefully remove the paper
More Information
Ref.
916115
Thickness (mm)
1.14
Surface material
Aluminium
Marking techniques
Dye sublimation
