Suitable for food consumption. They do not transfer flavour to the drink
Flat screw cap (Ref. 055294 and 056382) or dome (Ref. 038253 and 056445)
Mouth size suitable for easy refilling and cleaning of the bottle
All bottles have a glossy white sublimable coating, except Ref. 056382, which is matte
White cardboard presentation box included
Food consumption label attached to the base of the bottle. Easily removable (Ref. 038253)
You can personalise the cylindrical area of the bottle with a mug press or for cylindrical objects
They can also be personalised with other techniques such as laser engraving, screen printing, adhesive vinyl, DTF and UV printing
THINGS TO KEEP IN MIND
Cap is not sublimable
When sublimating with a press, keep the following in mind:
At the end of the pressing time, without removing the bottle from the press, rotate it and apply heat for 10 seconds more
This will allow the part of the design that remains on the sides of the paper to transfer evenly, just like the central area of the design
If there are residues on the surface after removing the sublimation paper, you can remove them with a soft damp cloth. The bottle must be completely cold
Although the box of the bottle with flat cap Ref. 055294 indicates it is 750 ml, its actual capacity is 650 ml
CHARACTERISTICS
Reference
055294
056382
038253
056445
Cap
Flat white
Flat white
Dome white
Dome silver
Coating finish
Glossy
Matte
Glossy
Glossy
Base design
Flat
Flat with rim
Flat with rim
Flat with rim
MEASUREMENTS
Reference
055294
056382
038253
056445
Capacity (oz ≈ ml)
23 ≈ 650
25 ≈ 700
25 ≈ 700
25 ≈ 700
Print area (cm)
22.5 x 11
22.5 x 11
22.5 x 12
22.5 x 13
Bottle (cm)
Ø6.9 x 25.5
Ø6.5 x 26.8
Ø7 x 25.5
Ø7 x 27.5
Cap (cm)
Ø4.2 x 2.5
Ø4.2 x 3
Ø4.2 x 3
Ø4.2 x 3
Mouth (cm)
Ø3.4 x 2.1
Ø3.4 x 1.9
Ø3.5 x 1.9
Ø3.4 x 2.1
WASHING RECOMMENDATIONS
Not suitable for use in dishwashers or microwaves
Hand wash with warm water and soap
Dry properly after each wash
RECOMMENDED SUBLIMATION INSTRUCTIONS AND PARAMETERS
Parameters indicated as guidelines. It is recommended to conduct prior tests to make necessary adjustments before starting production.
WITH MUG PRESS
Print the design in mirror mode
Heat the press to 180 ºC
Remove the cap from the bottle
Place the printed part of the paper on the bottle and secure them with heat-resistant tape
Insert the bottle into the press
Close the press with medium pressure for 60 seconds
After the pressing time, rotate the bottle without removing it from the press and apply heat for 10 seconds more
With the help of a protective glove, remove the freshly printed bottle
Carefully remove the paper
WITH SUBLIMATION OVEN
Print the design in mirror mode
Heat the oven to 180 ºC
Remove the cap from the bottle
Place the printed design around the bottle and secure them with heat-resistant tape
Place and adjust the clamp or, insert the bottle into a heat shrink bag and shrink with the gun. You can also use a silicone sheet
Sublimate in the oven for 6 minutes
With the help of a protective glove, remove the clamp, silicone sheet, or bag, as applicable
