Suitable for food consumption. No flavour transfer to the drink
Inside made of 304 stainless steel, for a longer shelf life. Favours the insulation thermal
Black lid with anti-leak silicone gasket. White (Ref. 054690) or black (Ref. 037031) plastic inner mouth
The lid opens by pressing the button. It has a hoop safety feature to prevent accidental opening
Mouth size suitable for easy filling and cleaning of thermos flasks
Black plastic base (Ref. 037031) or white stainless steel with embossed (Ref. 054690)
It can also be customised by other techniques such as screen printing, adhesive vinyl, DTF and printing UV
They are presented individually boxed
THINGS TO KEEP IN MIND
The thermoses have different sizes but the same liquid capacity (500 ml)
The thermos with black base, due to its shape, is easily sublimable on its entire surface (Ref. 037031). The one with white base is cylindrical only in its central part. It is advisable to sublimate it leaving 1,5/2 cm of space between the design and its ends (rim and base) (Ref. 054690)
The black base of the thermos should be removed before sublimating. To put it back on, just press it (Ref. 037031)
CHARACTERISTICS
Reference
054690
037031
Sublimation
Full
Partial
Cover
Black
Black
Mouth lid
White
Black
Latch lid
Thread Safety lock Push button release
Thread Safety lock Push button opening
Base thermos flask
White stainless steel
Black plastic
Inside thermos flask
Double wall
Thicker double wall
DIMENSIONS
Article number
054690
037031
Capacity (ml ≈ oz)
500 ≈ 17
500 ≈ 17
Thermos (cm)
Ø6,2 x 22,4
Ø6.5 x 24.7
Mouth (cm)
Ø4,5 x 2
Ø5,3 x 2
Print area (cm)
19,7 x 15
20,8 x 19
Presentation box (cm)
7 x 23,4 x 7
7,7 x 25 x 7,7
Weight (g)
198
303
RECOMMENDED INSTRUCTIONS AND PARAMETERS FOR SUBLIMATION PRINTING
Parameters given for guidance only. It is recommended to carry out preliminary tests in order to make the necessary adjustments before starting production.
WITH CUP IRON
Print the design in mode mirror
Preheat the press to 200 ºC
Remove the lid and the base of the thermos flask
Place the paper with the printed design around the thermos flask and fix it with heat adhesive tape
Close the press with medium pressure for 35 seconds
With the help of a protective glove retirael thermos flask freshly printed
Carefully remove the paper
WITH A SUBLIMATION OVEN
Print the design in mode mirror
Heat the oven to 200 ºC
Remove the lid from the water bottle
Place the printed design around the thermos and fix it with heat seal tape
Place and tighten the clamp or insert the thermos into a shrink bag and heat seal with the heat gun. You can also use a silicone film
Sublime in the oven for 6-7 minutes
With the help of a protective glove, remove the freshly sublimated thermos flask
