SUBLI-FLEX 4675 is a heat-adhesive sublimable polyester fabric (white) for textile transfer on light and dark fabrics.
Sublimable on the textured fabric side
First, print the sublimation paper and then sublimate the vinyl. Finally, transfer it to the garment
The support or liner is a siliconized paper of 135 g/m2
The 25-metre roll has a cardboard core of Ø7.5 cm
Manufactured in Germany by Poli-Tape
THINGS TO KEEP IN MIND
For small designs with many details, it may be convenient to use a transfer tape to facilitate the application of the vinyl. In such cases, it is recommended to use the Poli-Tack 853 transfer tape, see Related Products
If using a transfer tape, note that being polyester, some ink may remain due to resublimation. To avoid this, we recommend a short press (2-3 seconds), remove the transfer tape from the vinyl, and finish pressing
After printing the vinyl with sublimation ink, let it dry. It can be transferred to the garment when the ink is dry to the touch
It should be printed using cut marks to be able to cut it with the plotter
SUBLIMATION PARAMETERS
Temperature: 190 ºC
Time: 40-50 seconds
Pressure: 3.5 bar [medium pressure]
TRANSFER PARAMETERS
Temperature: 155-165 ºC
Pressure: 2.5-3.0 bar [medium pressure]
Time: 17-20 seconds
APPLICATION INSTRUCTIONS
STEP 1. SUBLIMATION OF THE VINYL
Print the sublimation paper in mirror mode
Heat the press to 190 ºC
Place the vinyl on the press
Place the printed side of the paper on the textured side of the vinyl
Press with medium pressure for 40-50 seconds
Remove the sublimated vinyl from the press
Let the ink dry
STEP 2. TRANSFER OF THE VINYL TO THE FABRIC
When the ink is dry to the touch, cut the sublimated vinyl with the plotter
Weed the excess vinyl (weeding operation)
If using a transfer tape, adhere it to the vinyl with the help of a squeegee
Heat the press to 155-165 ºC
Place the garment on the press and pre-press for 4-5 seconds to remove wrinkles and moisture from the fabric
Place the vinyl on the garment with the sublimated side facing up
Proper handling of this product will not lead to the formation or release of hazardous components. This product is not classified as dangerous goods under current GefStoffV legislation or under European Union criteria. Therefore, the preparation of a safety data sheet is not mandatory in this case. The safety data sheet is only intended to fulfil the information requirements under statute (EG) No. 1907/2006 (REACH) and can be provided upon request. This product is neither classified as dangerous goods under transport legislation nor composed of high-risk liquid substances, complying with household health regulations. Waste generated from the application and end-of-life cycle of the product must comply with the legal disposal standards corresponding to the respective national entities.
https://www.brildor.com/en/sublimable-textile-vinyl-gloss-poli-flex-4675-poli-tape25418Sublimable Textile Vinyl Gloss - Poli-Flex 4675 by Poli-Tape<p class="enlace"><a id="know-more"></a> </p>
<h2>More information about the dye sublimable glossy textile vinyl - Poli-Flex 4675 by Poli-Tape</h2>
<p> </p>
<p><strong>INDEX</strong></p>
<p><a href="#know-more1">Description</a></p>
<p><a href="#know-more2">Things to keep in mind</a></p>
<p><a href="#know-more3">Sublimation parameters</a></p>
<p><a href="#know-more4">Transfer parameters</a></p>
<p><a href="#know-more5">Application instructions</a></p>
<p><a href="#know-more6">Wash resistance</a></p>
<p><a href="#know-more7">Weights</a></p>
<p><a href="#know-more8">Related posts</a></p>
<p><a href="#know-more9">Technical data sheet</a></p>
<p><a href="#know-more10">Safety data sheet</a></p>
<p> </p>
<p class="enlace"><a id="know-more1"></a> </p>
<p><strong>DESCRIPTION</strong></p>
<p>SUBLI-FLEX 4675 is a <strong>heat-adhesive sublimable polyester fabric</strong> (white) for textile transfer on light and dark fabrics.</p>
<ul>
<li>Sublimable on the <strong>textured fabric side</strong></li>
<li>First, print the sublimation paper and then sublimate the vinyl. Finally, transfer it to the garment</li>
<li>The <strong>support</strong> or <strong>liner</strong> is a siliconized paper of <span class="azul-negrita">135 g/m<sup>2</sup></span></li>
<li>The <strong>25-metre</strong> roll has a cardboard core of <span class="azul-negrita">Ø7.5 cm</span></li>
<li>Manufactured in Germany by Poli-Tape</li>
</ul>
<p> </p>
<p class="enlace"><a id="know-more2"></a> </p>
<p><strong>THINGS TO KEEP IN MIND</strong></p>
<ul>
<li>For small designs with many details, it may be convenient to use a transfer tape to facilitate the application of the vinyl. In such cases, it is recommended to use the <strong>Poli-Tack 853</strong> transfer tape, see <strong>Related Products</strong></li>
<li aria-level="1">If using a transfer tape, note that being polyester, some ink may remain due to resublimation. To avoid this, we recommend a short press (<span class="azul-negrita">2-3 seconds</span>), remove the transfer tape from the vinyl, and finish pressing</li>
<li>After printing the vinyl with sublimation ink, let it dry. It can be transferred to the garment when the ink is dry to the touch</li>
<li aria-level="1">It should be printed using cut marks to be able to cut it with the plotter</li>
</ul>
<p> </p>
<p class="enlace"><a id="know-more3"></a> </p>
<p><strong>SUBLIMATION PARAMETERS</strong></p>
<ul>
<li>Temperature: <span class="azul-negrita">190 ºC</span></li>
<li>Time: <span class="azul-negrita">40</span><span class="azul-negrita">-50 seconds</span></li>
<li>Pressure: <span class="azul-negrita">3.5 bar</span> [medium pressure]</li>
</ul>
<p> </p>
<p class="enlace"><a id="know-more4"></a> </p>
<p><strong>TRANSFER PARAMETERS</strong></p>
<ul>
<li>Temperature: <span class="azul-negrita">155</span><span class="azul-negrita">-165 ºC</span></li>
<li>Pressure: <span class="azul-negrita">2.5-3.0 bar</span> [medium pressure]</li>
<li>Time: <span class="azul-negrita">17</span><span class="azul-negrita">-20</span><span class="azul-negrita"> seconds</span></li>
</ul>
<p> </p>
<p class="enlace"><a id="know-more5"></a> </p>
<p><strong>APPLICATION INSTRUCTIONS</strong></p>
<p><strong>STEP 1. SUBLIMATION OF THE VINYL</strong></p>
<ul>
<li>Print the sublimation paper in <strong>mirror mode</strong></li>
<li>Heat the press to <span class="azul-negrita">190 ºC</span></li>
<li>Place the vinyl on the press</li>
<li>Place the printed side of the paper on the textured side of the vinyl</li>
<li>Press with <strong>medium pressure</strong> for <span class="azul-negrita">40-50 seconds</span></li>
<li>Remove the sublimated vinyl from the press</li>
<li>Let the ink dry</li>
</ul>
<p><strong>STEP 2. TRANSFER OF THE VINYL TO THE FABRIC</strong></p>
<ul>
<li>When the ink is dry to the touch, cut the <strong>sublimated vinyl</strong> with the plotter</li>
<li>Weed the excess vinyl (weeding operation)</li>
<li>If using a transfer tape, adhere it to the vinyl with the help of a squeegee</li>
<li>Heat the press to <span class="azul-negrita">155-165 ºC</span></li>
<li>Place the garment on the press and pre-press for <span class="azul-negrita">4-5 seconds</span> to remove wrinkles and moisture from the fabric</li>
<li>Place the vinyl on the garment with the sublimated side facing up</li>
<li>Place protective paper</li>
<li>Remove the transfer sheet <strong>while hot</strong></li>
<li>Press with medium pressure for <span class="azul-negrita">17-20 seconds</span></li>
<li>Remove the liner from the vinyl</li>
</ul>
<p> </p>
<p class="enlace"><a id="know-more6"></a> </p>
<p><strong>WASH RESISTANCE</strong></p>
<ul>
<li>Wash resistance: max. <span class="azul-negrita">90º C</span></li>
<li>Wash the garment inside out</li>
<li>Use only colour detergent</li>
</ul>
<p> </p>
<p class="enlace"><a id="know-more7"></a> </p>
<p><strong>WEIGHTS</strong></p>
<table>
<tbody>
<tr>
<td>Roll (m)</td>
<td style="text-align: center;"><span class="azul-negrita">1</span></td>
<td style="text-align: center;"><span class="azul-negrita">5</span></td>
<td style="text-align: center;"><span class="azul-negrita">25</span></td>
</tr>
<tr>
<td>Weight (kg)</td>
<td style="text-align: center;"><span class="azul-negrita">0.187</span></td>
<td style="text-align: center;"><span class="azul-negrita">0.935</span></td>
<td style="text-align: center;"><span class="azul-negrita">4.675</span></td>
</tr>
</tbody>
</table>
<p> </p>
<p class="enlace"><a id="know-more8"></a> </p>
<p><strong>RELATED POSTS<br></strong></p>
<p><a title="Complete Guide on Printable Textile Vinyl" href="https://www.brildor.com/blog/es/guia-completa-sobre-vinilo-textil-imprimible/" target="_blank" rel="nofollow noopener">Complete Guide on Printable Textile Vinyl</a></p>
<p> </p>
<p class="enlace"><a id="know-more9"></a> </p>
<p><strong>TECHNICAL DATA SHEET</strong></p>
<p><a title="Poli-Flex 4675 Technical Data Sheet" href="https://www.brildor.com/media/upload/descargas/Ficha_Tecnica_Vinilo_Textil_Sublimable_Poli_Flex_4675_Poli_Tape.pdf" target="_blank" rel="nofollow noopener">Poli-Flex 4675 Technical Data Sheet (.pdf - 0.06 MB)</a></p>
<p> </p>
<p class="enlace"><a id="know-more10"></a> </p>
<p><strong>SAFETY DATA SHEET</strong></p>
<p>Proper handling of this product will not lead to the formation or release of hazardous components. This product is not classified as dangerous goods under current GefStoffV legislation or under European Union criteria. Therefore, the preparation of a safety data sheet is not mandatory in this case. The safety data sheet is only intended to fulfil the information requirements under statute (EG) No. 1907/2006 (REACH) and can be provided upon request. This product is neither classified as dangerous goods under transport legislation nor composed of high-risk liquid substances, complying with household health regulations. Waste generated from the application and end-of-life cycle of the product must comply with the legal disposal standards corresponding to the respective national entities.</p>https://www.brildor.com/media/catalog/product/v/i/vinilo-textil-sublimable-brillo-poli-flex-4675-poli-tape.jpg8.49instock08.49000https://www.brildor.com/media/catalog/product/v/i/vinilo-textil-sublimable-brillo-poli-flex-4675-poli-tape.jpg255674468048728/Sublimation/Vinyl/Sublimation/Sublimation on Cotton/Vinyl/Sublimation Heat Transfer Vinyl2021-07-24T06:11:32+0000
