1 smooth side (front side sublimatable) and 1 textured side (back side)
The pre-cut canvases have L-shaped die-cut corners for easy mounting on the frame
The 100 cm x 10 m roll has a Ø4.8 cm cardboard core or inner tube
THINGS TO KEEP IN MIND
They can be easily attached to the frame using a stapler, nailer or double-sided tape. You will find them in Related Products
You can buy wooden frames with other profiles and sizes at Related Products (Ref. 916776)
The canvas must cover the edge of the frame so that it is hidden on the back. Therefore, the canvas size must be at least 2.5 cm larger than each side of the frame. For example, for a frame of 20 x 30 cm, the appropriate canvas would be 27 x 36.5 cm
DIMENSIONS
PRE-CUT CANVASES (*)
Reference
Outside (cm)
Inside (cm) (**)
Compatible frame (cm)
000213
24 x 32
20 x 24,5
16,5 x 25 (Ref. 000216)
000212
27 x 36,5
23 x 29,5
20 x 30 (Ref. 000215)
000211
36 x 36
29 x 31,5
30 x 30 (Ref. 000210)
000214
32 x 44
27,5 x 36,5
25 x 37 (Ref. 000217)
000208
37 x 47
32,5 x 40
30 x 40 (Ref. 000209)
(*) Approximate values provided for guidance only. They may vary slightly due to the normal irregularities in the cutting process of the canvas.
(**) Area enclosed by the corners L-shaped.
ROLLS
Reference
049982
049983
049985
049984
Roll width (cm)
100
100
45
45
Length (cm)
2,5
10
2,5
10
Outside diameter (cm)
Ø6
Ø10
Ø6
Ø10
Mandrel or inner tube (cm)
-
Ø4,8
-
-
Weight (kg)
0,5
3,12
0,4
1,44
RECOMMENDED INSTRUCTIONS AND PARAMETERS FOR SUBLIMATION PRINTING
Print on design in mode mirror
Preheat the press to 200 ºC
Place the canvas on the base of the plate and the printed part of the paper on the canvas. Fix them with thermal adhesive tape
Close the press at medium pressure for 40 seconds
With the help of a protective glove, remove the freshly printed canvas
Carefully remove the paper
HOW TO FIX THE CANVAS ON THE STRETCHER FRAME?
Stretch the canvas with the sublimated side down on a flat, clean surface
Place the stretcher frame centred on the back of the canvas
Staple the centre of each side of the frame first. Use a pair of pliers to tighten and staple the opposite sides. You will find them in Related Products (Ref. 003676)
Next, staple both sides of the central staples progressively towards the corners
Fold the corners of the canvas inwards and staple them to the frame
