Double wall: inside of 304 stainless steel and outside of stainless steel 201
Screw cap with hole to fit the straw (included)
Glossy finish
Customisable with sublimation oven using mug wraps, silicone sheets o heat shrink bags
Packaged in a box from white cardboard
THINGS TO KEEP IN MIND
Orca certification attached as a sticker on the base. It can be easily removed if desired
DIMENSIONS
Capacity (oz ≈ ml)
17 ≈ 500
Mouth (cm)
Ø7,3
Base (cm)
Ø8,5
Height (cm)
14,2
Lid (cm)
7,8 x 1,9
Hole for straw (cm)
Ø0,8
Straw (cm)
Ø0,7 x 19,2
Handle (cm)
0,9 x 6,9
Distance stein-handle (cm)
3,8
Print area (cm)
25,5 x 11
Weight (g)
232
RECOMENDED INSTRUCTIONS AND PARAMETERS FOR SUBLIMATION PRINTING
Parameters are given for guidance only. It is recommended to carry out preliminary tests in order to make the necessary adjustments before starting production.
Print on design in mode mirror
Heat the oven to 200 ºC
Place the printed design around the stein and fix it with adhesive heat tape
Tighten the clamp or insert the stein inside a heat-shrink bag and heat with the heat shrink stripping gun avoiding the formation of wrinkles. You can also use a silicone sheet
Sublimate in the oven for 5 minutes
Using a protective glove, remove the wrap, the silicone sheet, or the bag, depending on the case
https://www.brildor.com/en/sublimatable-stainless-steel-thermo-mug-lid-straw48864Sublimatable Stainless Steel Thermo Mug with Lid and Straw<p class="enlace"><a id="saber-mas"></a> </p>
<h2>More information about the Sublimatable Stainless Steel Thermo Mug with Lid and Straw</h2>
<p> </p>
<p><strong>INDEX</strong></p>
<p>> <a href="#saber-mas1">Description</a></p>
<p>> <a href="#saber-mas2">Things to keep in mind</a></p>
<p>> <a href="#saber-mas3">Dimensions</a></p>
<p>> <a href="#saber-mas4">Recommended instructions and parameters for sublimation printing</a></p>
<p>> <a href="#saber-mas5">Related post</a></p>
<p> </p>
<p class="enlace"><a id="saber-mas1"></a> </p>
<p><strong>DESCRIPTION</strong></p>
<ul>
<li>Double wall: inside of <strong>304 stainless steel</strong> and outside of<strong> stainless steel 201</strong></li>
<li>Screw cap with hole to fit the straw (included)</li>
<li>Glossy finish</li>
<li>Customisable with sublimation oven using mug wraps, silicone sheets o heat shrink bags</li>
<li>Packaged in a box from white cardboard</li>
</ul>
<p> </p>
<p class="enlace"><a id="saber-mas2"></a> </p>
<p><strong>THINGS TO KEEP IN MIND<br></strong></p>
<ul>
<li>Orca certification attached as a sticker on the base. It can be easily removed if desired</li>
</ul>
<p> </p>
<p class="enlace"><a id="saber-mas3"></a> </p>
<p><strong>DIMENSIONS</strong></p>
<table>
<tbody>
<tr>
<td><strong>Capacity (oz ≈ ml)<br></strong></td>
<td style="text-align: left;"><span class="azul-negrita">17 ≈ 500</span></td>
</tr>
<tr>
<td><strong>Mouth (cm)<br></strong></td>
<td style="text-align: left;"><span class="azul-negrita">Ø7,3<br></span></td>
</tr>
<tr>
<td><strong>Base (cm)</strong></td>
<td style="text-align: left;"><span class="azul-negrita">Ø8,5<br></span></td>
</tr>
<tr>
<td><strong>Height (cm)</strong></td>
<td style="text-align: left;"><span class="azul-negrita">14,2<br></span></td>
</tr>
<tr>
<td><strong>Lid (cm)</strong></td>
<td style="text-align: left;"><span class="azul-negrita">7,8 x 1,9<br></span></td>
</tr>
<tr>
<td><strong>Hole for straw (cm)<br></strong></td>
<td style="text-align: left;"><span class="azul-negrita">Ø0,8</span></td>
</tr>
<tr>
<td><strong>Straw (cm)<br></strong></td>
<td style="text-align: left;"><span class="azul-negrita">Ø0,7 x 19,2<br></span></td>
</tr>
<tr>
<td><strong>Handle (cm)<br></strong></td>
<td class="azul-negrita" style="text-align: left;">0,9 x 6,9</td>
</tr>
<tr>
<td><strong>Distance stein-handle (cm)<br></strong></td>
<td class="azul-negrita" style="text-align: left;">3,8</td>
</tr>
<tr>
<td><strong>Print area (cm)<br></strong></td>
<td class="azul-negrita" style="text-align: left;">25,5 x 11</td>
</tr>
<tr>
<td><strong>Weight (g)<br></strong></td>
<td class="azul-negrita" style="text-align: left;">232</td>
</tr>
</tbody>
</table>
<p> </p>
<p class="enlace"><a id="saber-mas4"></a> </p>
<p><strong>RECOMENDED INSTRUCTIONS AND PARAMETERS FOR SUBLIMATION PRINTING</strong></p>
<p>Parameters are given for <strong>guidance only</strong>. It is recommended to carry out preliminary tests in order to make the necessary adjustments before starting production.</p>
<ul>
<li>Print on design in <strong>mode</strong> <strong> mirror</strong></li>
<li>Heat the oven to <span class="azul-negrita">200 ºC</span></li>
<li>Place the printed design around the stein and fix it with adhesive heat tape</li>
<li>Tighten the clamp or insert the stein inside a heat-shrink bag and heat with the heat shrink stripping gun avoiding the formation of wrinkles. You can also use a silicone sheet</li>
<li>Sublimate in the oven for <span class="azul-negrita">5 minutes</span></li>
<li>Using a protective glove, remove the wrap, the silicone sheet, or the bag, depending on the case</li>
<li>Carefully peel off the paper of the stein</li>
</ul>
<p> </p>
<p class="enlace"><a id="saber-mas5"></a> </p>
<p><strong>RELATED POST<br></strong></p>
<p><a href="https://www.brildor.com/blog/en/oven-sublimation-using-heat-shrink-bags/" target="_blank" rel="nofollow noopener">Oven sublimation using heat shrink bags</a></p>https://www.brildor.com/media/catalog/product/t/a/taza-termo-inox-blanca-sublimacion-tapa-pajita.jpg9.95instock9.959.9500000https://www.brildor.com/media/catalog/product/t/a/taza-termo-inox-blanca-sublimacion-tapa-pajita.jpg20392229612558048350/Blanks/Blanks/Beer Steins & Tumblers/Blanks/Beer Steins & Tumblers/Beer Steins/Blanks/Mugs, Beer Steins & Tumblers/Blanks/Thermos Flasks2022-10-24T10:25:45+0000
