When used under normal conditions, this product does not generate or release any dangerous substances or hazardous chemicals. This is a non-hazardous product in accordance with the current GefStoffV and EU criteria. Therefore it is not necessary to prepare a Material Safety Data Sheet for this product. The Safety Data Sheet serves only to comply with the regulation to supply information in accordance with REACH Regulation (EC) No. 1907/2006 and is available on request. This product is not a hazardous product with regards to transportation legislation; neither does it contain substances that are hazardous to water within the meaning of the federal water act. After use, dispose of the waste product in accordance with the local / national authorities.
https://www.brildor.com/en/ultimate-print-nylon-4035-printable-htv-poli-tape43708Matte Printable Heat Transfer Vinyl - Ultimate Print Nylon 4035<p><a name="know-more"></a></p>
<h2>More information about the matt printable textile film - Ultimate Print Nylon 4035 from Poli-Tape</h2>
<p> </p>
<p><strong>INDEX</strong></p>
<p><a href="#know-more1">Description</a></p>
<p><a href="#know-more2">Things to keep in mind</a></p>
<p><a href="#know-more3">Parameters</a></p>
<p><a href="#know-more4">Application instructions</a></p>
<p><a href="#know-more5">Vinyl dimensions</a></p>
<p><a href="#know-more6">Wash resistance</a></p>
<p><a href="#know-more9">Data sheet</a></p>
<p><a href="#know-more10">Safety data sheet</a></p>
<p> </p>
<p><a name="know-more1"></a></p>
<p><strong>DESCRIPTION</strong></p>
<p>Ultimate Print Nylon 4035 is a <strong>heat sealing adhesive</strong> <strong>PU (polyurethane) film</strong> (opaque white, <span class="azul-negrita">100 µ</span>) for textile transfer.</p>
<ul>
<li>Suitable for stretch, softshell or hydrophobic fabrics, i.e. highly water-repellent</li>
<li>Special hotmelt coating. The adhesive melts and moulds to the fabric. Once cold, the vinyl recovers its rigidity and remains attached to the garment</li>
<li>Elastic and high opacity properties with a pleasant soft touch</li>
<li>The <strong>liner</strong> is a <span class="azul-negrita">100 µ</span> non-adhesive <strong>PET (polyester) film</strong></li>
<li>The raw materials are ecologically inert, do not contain PVC, plasticizers or heavy metals (in accordance with <strong>OEKO-TEX Standard 100 Class I</strong>)</li>
</ul>
<p> </p>
<p><a name="know-more2"></a></p>
<p><strong>THINGS TO KEEP IN MIND</strong></p>
<ul>
<li>Non-adhesive liner. To transfer the design to the garment we recommend using the <strong>Poli-Tack 853</strong> or <strong>Poli-Tack 854</strong> transfer tape, see <strong>Related Products</strong></li>
<li>For detailed print settings, access the vinyl <a href="https://www.poli-tape.de/en/products/textile-graphics/icc-profiles-textile-graphics" target="_blank" rel="nofollow noopener">ICC profiles</a> (for some plotters)</li>
</ul>
<p> </p>
<p><a name="know-more3"></a></p>
<p><strong>PARAMETERS</strong></p>
<ul>
<li>Knife blade: <span class="azul-negrita">45º</span></li>
<li>Temperature: <span class="azul-negrita">150ºC</span></li>
<li>Pressure: <span class="azul-negrita">2.5 - 3.0 bar</span> (medium pressure)</li>
<li>Time:
<ul>
<li><span class="azul-negrita">5 seconds </span>(first pressing)<span class="azul-negrita"><br></span></li>
<li><span class="azul-negrita">10-15 seconds </span>(second pressing)</li>
</ul>
</li>
</ul>
<p> </p>
<p><a name="know-more4"></a></p>
<p><strong>APPLICATION INSTRUCTIONS<br></strong></p>
<ul>
<li>Print the design in <strong>direct mode</strong></li>
<li>Cut it with a plotter</li>
<li>Weed out your excess vinyl</li>
<li>Adhere the Poli-Tack 853 or 854 application tape with the help of a scraper</li>
<li>Preheat the press to <span class="azul-negrita">150ºC</span></li>
<li>Place the garment on the press and pre-iron for <span class="azul-negrita">4-5 seconds</span> to remove wrinkles and moisture from the fabric</li>
<li>Position the vinyl on the garment</li>
<li>Press for <span class="azul-negrita">4 seconds</span>, medium pressure</li>
<li><strong>Hot peel</strong> the transfer tape</li>
<li>Remove the liner when <strong>lukewarm</strong></li>
<li>Press again for <span class="azul-negrita">10- 15 seconds</span>, medium pressure</li>
</ul>
<p> </p>
<p><a name="know-more5"></a></p>
<p><strong>VINYL DIMENSIONS</strong></p>
<table>
<tbody>
<tr>
<td style="text-align: center;"><strong>Reference<br></strong></td>
<td style="text-align: center;"><strong>Width (cm)<br></strong></td>
<td style="text-align: center;"><strong>Length (m)<br></strong></td>
<td style="text-align: center;"><strong>Outer diameter (cm)</strong></td>
<td style="text-align: center;"><strong>Core (cm)</strong></td>
<td style="text-align: center;"><strong>Box (cm)</strong></td>
<td style="text-align: center;"><strong>Weight (kg)</strong></td>
</tr>
<tr>
<td style="text-align: center;"><strong>045456</strong></td>
<td class="azul-negrita" style="text-align: center;">50</td>
<td class="azul-negrita" style="text-align: center;">5</td>
<td style="text-align: center;"><span class="azul-negrita">Ø5</span></td>
<td style="text-align: center;">-</td>
<td style="text-align: center;">-</td>
<td style="text-align: center;"><span class="azul-negrita">0.670</span></td>
</tr>
<tr>
<td style="text-align: center;"><strong>045455</strong></td>
<td style="text-align: center;"><span class="azul-negrita">50</span></td>
<td style="text-align: center;"><span class="azul-negrita">25</span></td>
<td style="text-align: center;"><span class="azul-negrita">Ø11.5</span></td>
<td style="text-align: center;"><span class="azul-negrita">Ø7.5</span></td>
<td style="text-align: center;"><span class="azul-negrita">52 x 14 x 14</span></td>
<td style="text-align: center;"><span class="azul-negrita">3.621</span></td>
</tr>
</tbody>
</table>
<p> </p>
<p><a name="know-more6"></a></p>
<p><strong>WASH RESISTANCE</strong></p>
<ul>
<li>Washing resistance: max <span class="azul-negrita">40ºC</span></li>
<li>Wash inside out</li>
</ul>
<p> </p>
<p><a name="know-more9"></a></p>
<p><strong>DATA SHEET</strong></p>
<p><a title="Data sheet Ultimate Print Nylon 4035" href="https://www.brildor.com/media/upload/downloads/Data_Sheet_Ultimate_Print_Nylon_Poli_Tape_4035_EN.pdf" target="_blank" rel="nofollow noopener">Data sheet Ultimate Print Nylon 4035 (.pdf - 49 ko)</a></p>
<p> </p>
<p><a name="know-more10"></a></p>
<p><strong>SAFETY DATA SHEET</strong></p>
<p>When used under normal conditions, this product does not generate or release any dangerous substances or hazardous chemicals. This is a non-hazardous product in accordance with the current GefStoffV and EU criteria. Therefore it is not necessary to prepare a Material Safety Data Sheet for this product. The Safety Data Sheet serves only to comply with the regulation to supply information in accordance with REACH Regulation (EC) No. 1907/2006 and is available on request. This product is not a hazardous product with regards to transportation legislation; neither does it contain substances that are hazardous to water within the meaning of the federal water act. After use, dispose of the waste product in accordance with the local / national authorities.</p>https://www.brildor.com/media/catalog/product/v/i/vinilo-textil-imprimible-ultimate-print-nylon-4035-d6.jpg37.95instock037.95000https://www.brildor.com/media/catalog/product/v/i/vinilo-textil-imprimible-ultimate-print-nylon-4035-d6.jpg181552195144680/Vinyl/Vinyl/Printable HTV2022-03-01T14:46:21+0000
